Mercury 4000 MPC GEN 2 User Manual

4000 MPC GEN 2 PISTOL GRIP REMOTE CONTROL INSTALLATION/OPERATION INSTRUCTIONS
Products of Mercury Marine
Mercury, Mercury Marine, MerCruiser, Mercury MerCruiser, Mercury Racing, Mercury Precision Parts,
Mercury Propellers, Mariner, Quicksilver, #1 On The Water, Alpha, Bravo, Pro Max, OptiMax, Sport-Jet,
K-Planes, MerCathode, SmartCraft, Zero Effort, M with Waves logo, Mercury with Waves logo, and
SmartCraft logo are all registered trademarks of Brunswick Corporation. Mercury Product Protection logo
is a registered service mark of Brunswick Corporation.
W6250 Pioneer Road
Fond du Lac, WI 54936-1939
90-899782001 APRIL 2008 Page 23 / 23
3. The control module shown on the template is mounted horizontally. Refer to item d.
25587
7.14 mm
7.14 mm
31.8 mm
108 mm
(9/32 in.)
(9/32 in.)
(1-1/4 in.)
(4-1/4 in.)
b
a
a
7.14 mm
(9/32 in.)
a
c
d
a - Machine screw drill size
b - Remove the sharp edges on the interior and exterior surfaces
c - Cut out only if equipped with a lanyard stop switch
d - Outline of starboard mounted panel control module
