CYLINDER BLOCK AND CRANKCASE
90-857138R1 MAY 2000 Page 4B–21
16. Remove the breather cap.
a
b
c
a-Screw (2)
b-Breather Cap
c-Gasket
17. Remove the breather tubes and wave washers.
a
b
a-Breather Tube (2)
b-Wave Washer (2)
