CYLINDER BLOCK AND CRANKCASE
Page 4B–28 90-857138R1 MAY 2000
Measuring Depth of Oil Pump Body
Standard Value Out of the Limit
0.236 in. (6.0 mm) If 0.238 in. (6.06 mm) or more requires replacement
Measuring Inside Diameter of Oil Pump Body
Standard Value Out of the Limit
0.909 in. (23.09 mm) If 0.910 in. (23.13 mm) or more requires
replacement
