CYLINDER BLOCK AND CRANKCASE
Page 4B–32 90-857138R1 MAY 2000
2. Install the breather tubes and wave washers.
a
b
a-Breather Tube (2)
b-Wave Washer (2)
3. Install the breather cap.
a
b
c
a-Screw (2)
b-Breather Cap
c-Gasket
Breather Cap Screw Torque
70 lb-in. (8 Nm)
