2. Fasten the rigging grommet and rigging adapter with two M6 x 30 screws
and one M6 x 50 screw. Tighten the screws to the specified torque.
3. Secure the wiring, hoses, and cables together with a cable tie.
NOTICE
Inspect the position of the hose clamp located on the fuel hose to ensure
that it will not chafe or cut into the adjacent wiring harnesses.
53884
Cable tie
Description Nm lb‑in. lb‑ft
Screws for attaching the rigging
adapter
6 53 –
OUTBOARD INSTALLATION
120 eng

Mercury 80 Specifications

General

Steering	Remote
Shaft Length	20 in (508 mm)
Gear Ratio	2.07:1
Horsepower	80 hp
Full Throttle RPM Range	5000-6000 RPM
Bore x Stroke	3.15 x 3.15 in (80 x 80 mm)
