Mercury 80 User Manual

4. Pull out the dipstick. Wipe the dipstick end with a clean rag or towel and
push it back in all the way.
5. Pull the dipstick back out again and observe the oil level. Oil should be in
the operating range (cross hatched region).
IMPORTANT: Do not try to fill the oil level to the top of the operating range
(cross hatched region). Oil level is correct as long as it appears in the
operating range (cross hatched region).
a - Oil level operating range
b - Top bar
c - Bottom bar
d - Upper 1/3 level
53753
a
b
c
d
FUEL AND OIL
eng 47

Mercury 80 Specifications

General

Steering	Remote
Shaft Length	20 in (508 mm)
Gear Ratio	2.07:1
Horsepower	80 hp
Full Throttle RPM Range	5000-6000 RPM
Bore x Stroke	3.15 x 3.15 in (80 x 80 mm)
