Mercury 80 User Manual

Tube Ref
No.
Description Where Used Part No.
95
2-4-C with PTFE Propeller shaft 92-802859A 1
•
Propeller shaft ‑ Refer to Propeller Replacement for removal and
installation of the propeller. Coat the entire propeller shaft with
lubricant to prevent the propeller hub from corroding and seizing to the
shaft.
47623
2. Lubricate the following with 2‑4‑C with PTFE or Extreme Grease.
Tube Ref
No.
Description Where Used Part No.
95
2-4-C with PTFE Steering cable 92-802859A 1
Extreme Grease Steering cable 8M0071842
• Steering cable grease fitting (if equipped) ‑ Rotate steering wheel to
fully retract the steering cable end into the outboard tilt tube. Lubricate
through fitting.
a - Fitting
b - Steering cable end
b
a
47651
MAINTENANCE
eng 81

Mercury 80 Specifications

General

Steering	Remote
Shaft Length	20 in (508 mm)
Gear Ratio	2.07:1
Horsepower	80 hp
Full Throttle RPM Range	5000-6000 RPM
Bore x Stroke	3.15 x 3.15 in (80 x 80 mm)
