WARNING
Incorrect cable lubrication can cause hydraulic lock, leading to serious
injury or death from loss of boat control. Completely retract the end of the
steering cable before applying lubricant.
• Tilt lever grease fitting and the swivel pin grease fitting.
a - Tilt lever grease fitting
b - Swivel pin grease fitting
3. Lubricate the following with lightweight oil.
• Steering link rod pivot points ‑ Lubricate pivot points.
47652
a
b
54186
MAINTENANCE
82 eng

Mercury 80 Specifications

General

Steering	Remote
Shaft Length	20 in (508 mm)
Gear Ratio	2.07:1
Horsepower	80 hp
Full Throttle RPM Range	5000-6000 RPM
Bore x Stroke	3.15 x 3.15 in (80 x 80 mm)
