Mercury 9.9 Service Manual

1
2
3
4
5
6
7
8
General Information
& Specifications
Electrical and Ignition
Fuel System
Powerhead
Mid-Section
Lower Unit
Attachments/
Control Linkage
Manual Starter
90-827242R02 FEBRUARY 2003 Page iii
Service Manual Outline
Section 1 - General Information & Specifications
A - Specifications
B - Maintenance
C - General Information
D - Outboard Installation
Section 2 - Electrical and Ignition
A - Ignition System
B - Charging & Starting System
C - Timing/Synchronizing & Adjusting
D - Wiring Diagrams
Section 3 - Fuel System
A - Fuel Delivery System
B - Emissions
Section 4 - Powerhead
Section 5 - Mid-Section
A - Clamp/Swivel Brackets and Driveshaft Housing
B - Power Trim
Section 6 - Lower Unit
Section 7 - Attachments/Control Linkage
A - Throttle/Shift Linkage (Tiller Handle Shift Models)
B - Throttle/Shift Linkage (Side Shift Models)
C - Tiller Handle
Section 8 - Manual Starter

Mercury 9.9 Specifications

General

Cylinders	2
Fuel Tank	External
Full Throttle RPM Range	5000 - 6000 RPM
Fuel Induction System	Carbureted
Alternator Amp	6 amp
Horsepower	9.9 hp
Starting	Manual
Shaft Length	15 in, 20 in
Steering	Tiller
