Drive Belts
WARNING
Avoid possible serious injury. Make sure engine is shut off
and ignition key is removed before inspecting belts.
V-Belts (3.0L Model)
CHECKING
1 Inspect the alternator and power steering pump drive belts for the
following:
• Excessive wear • Fraying
• Cracks • Glazed surfaces
2 Check belt tension by depressing belts, with moderate hand
pressure, at points shown.
A Alternator Belt - Belt should depress 1/2 in. (13 mm).
B Power Steering Pump Drive Belt (If So Equipped) - Belt should de-
press 1/4 in. (6 mm).
REPLACING
Alternator Belt
3 Remove as follows:
A Remove power steering belt as outlined in the following.
B Remove the two port side, front engine mount bracket assembly
screws and washers.
C Remove the spacer block between the bracket assembly and the
engine block. It may be necessary to tap gently on the spacer to
allow removal.
To Next Page
