Table of Mainboard Components
Label Component
AGP1 Accelerated Graphics Port
ATX1 Power connector
BT1 Three volt realtime clock battery
CASFAN1 Auxiliary case cooling fan
CD1 Primary CD-in connector
CD2 Secondary CD-in connector
CNR1 Communications Networking Riser slot
CPUFAN1 Cooling fan for CPU
DDR1~DDR2 Two 184 pin DDR SDRAM
DIMM1 ~ DIMM2 Two 168 pin DIMM sockets
FDD1 Floppy disk drive connector
IDE 1 Primary IDE channel
IDE 2 Secondary IDE channel
J2 Front-oriented microphone/line-out port header
J4 Sleep switch
J5 Single color power LED
JP1 Clear CMOS jumper
JP3 BIOS protection jumper
JP4 CPU frequency selection jumper
JP5A/B/C/D,
JP6A/B/C/D
DDR/SDR DRAM type selector
JP7 DDR/ SDR DRAM voltage switch
JP8 CPU voltage control
PANEL1
Connector for case front panel switches and LED indica-
tors
PCI1 ~ PCI5 Five 32-bit add-in card slots
SIR1 Serial infrared cable header
SOCKET 462 Socket A for AMD Athlon processor
SPEAKER Speaker connector
USB2 Front panel USB headers
WOL1 Wake On LAN wakeup connector
WOM1 Wake On Modem wakeup connector
This concludes Chapter 1. The next chapter explains how to install the main-
board.
