Connecting Optional Devices

Refer to the following for information on connecting the mainboard’s optional

devices:

J2: Front panel MIC/line-out

This header allows the user to install auxiliary front-oriented microphone and

line-out ports for easier access.

Pin Signal Name Pin Signal Name

FMICIN

MIC_BIAS

SPKOUTR

SPKOUTL

GND

+5V

C-SPK0-R

KEY

C-SPK0-L
