SERVICE MANUAL NUMBER 23

90-861326--1 MARCH 1999 Page 7D-9

(1.)Position tube so that “SIDE” markings on tube are facing toward the right and

left sides.

(2.)Install clamp.

(3.)Tighten clamp securely.

22184

a-Exhaust Tube

b-Clamp

c-“Side” Marking

d-Exhaust Tube

e-Grounding Clip

72539

a-Silencer Valve Assembly

b-Hose Clamps
