Mercury MotorGuide VariMAX User Manual

PRODUCT OVERVIEW AND ASSEMBLY
10 eng
2. Align the handle to the top housing using the flat groove on the
extension handle. The handle extension spring should face up.
a - Top housing
b - Handle extension spring
c - Cam lock
d - Handle
3. Press the handle extension spring in while inserting the handle into
the top housing. Adjust the handle to the desired length.
a - Handle extension spring
a
b
c
d
45687
a
45690
