Mercury MotorGuide VariMAX User Manual

PRODUCT OVERVIEW AND ASSEMBLY
eng 11
4. Rotate the cam lock clockwise 180°. Move the cam lock flush
against the top housing.
180°
39062
5. To secure the handle, hold the handle steady while rotating and
tightening the cam lock clockwise 180°. Verify that the flat surfaces
of the handle, cam lock, and top housing are in alignment.
a - Top housing
b - Cam lock
c - Handle
a
b
c
45694
