Mercury OptiMax 250 Manual

DIRECT FUEL INJECTION
Page 3B-13
90-888438 JUNE 2002
Vapor Separator Components
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 COVER KIT
2 1 FITTING-Straight 65 7.3
3 1 FITTING-Elbow 50 5.7
4 1 SEAL
5 1 FITTING KIT-Pump Outlet 75 8.5
6 1 O RING
7 7 SCREW (#8-32 x .750) 22 2.5
8 1 GASKET
9 1 FLOAT KIT
10 1 SHAFT-Float
11 1 NEEDLE VALVE
12 1 SCREW (#6-32 x .187) 10 1.0
13 1 FUEL PUMP ASSEMBLY
14 1 SLEEVE
15 1 BOWL KIT
16 1 SEAL
17 1 PLUG KIT
18 1 O-RING
19 1 FITTING-Elbow 65 7.3
20 1 FITTING-Elbow 65 7.3
21 1 FITTING-Elbow 65 7.3
22 1 FUEL FILTER KIT
23 1 PROBE-Water Sensing 22 2.5
24 1 PLUG (.125-27)
25 3 BUSHING
26 6 WASHER
27 3 GROMMET
28 3 SCREW (M8 X 35)
