Mercury OptiMax 250 Manual

DIRECT FUEL INJECTION
Page 3B-9
90-888438 JUNE 2002
Air Handler Components
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
– 1 AIR HANDLER
1 1 ADAPTOR PLATE
2 1 GASKET
3 6 REED BLOCK
4 12 SCREW (M6 x 1) 90 10.2
5 3 BUSHING
6 3 GROMMET
7 3 WASHER
8 3 SCREW (M8 x 30) 150 17
9 1 AIR PLENUM KIT
10 1 GASKET
11 2 SCREW (M4 x 16) 22 2.5
12 1 SENSOR–MAP
13 1 BRACKET
14 1 TEMPERATURE SENSOR
15 1 O RING
16 1 THROTTLE BODY KIT
17 4 SCREW (M6 x 40) 65 7.3
18 1 O RING
19 1 OIL PUMP
20 1 ROLLER
21 1 THROTTLE ROLLER
22 1 SCREW 22 2.5
23 1 WASHER-Cupped
24 1 WASHER-Spool
25 1 LOCKWASHER (#10 External)
26 1 RETAINING RING
27 2 RETAINER-Hose Support
28 1 CLAMP
29 6 CHECK VALVE 40 4.5
30 1 SCREW (M6 x 16) 38 4.3
31 1 FILTER ASSEMBLY-Air
32 12 SCREW (M6 x 40) 120 13.6
33 2 WASHER
34 1 COVER ASSEMBLY-Flywheel
35 3 GROMMET
36 1 PLUG
37 2 GROMMET
38 1 ATTENUATOR ASSEMBLY-Air
39 1 BUSHING
40 1 GROMMET
