DIRECT FUEL INJECTION
Page 3B-3
90-888438 JUNE 2002
Special Tools
1. Duel Fuel/Air Pressure Gauge 160 psi – 91-852087A1/A2/A3
a
57818
a-Schrader Valve “Tee” (22-849606)
2. Adaptors to convert pressure gauge 91-852087A1/A2 to an A23
NOTE: 2 Adaptors 91-803804A2 are required to convert a pressure gauge set.
a
b
c
d
a-1/2 in. to 1/4 in. Adapter (if required)
b-Female Quick Disconnect
c-Male Quick Disconnect
d-Screw on Schrader
3. Screw (5 mm x 25 mm) (2 each) – 10-40073-25
4. Flat Washer (2 each) – 12-30164
5. Seal/Teflon Ring Installation Tool – 91-851980
56015
6. Seal/Teflon Ring Sizing Tool – 91-851980-1
56014
