Mercury OptiMax 250 Manual

DIRECT FUEL INJECTION
Page 3B-15
90-888438 JUNE 2002
Fuel Rails
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 6 AIR INJECTOR KIT
2 6 WASHER ASSEMBLY-Cupped
3 1 FUEL RAIL (PORT)
4 1 FUEL RAIL (STARBOARD)
5 1 FITTING
6 1 O-RING KIT
7 4 CLAMP
8 15 SCREW (M5 x 8) 70 8
9 2 CAP
10 1 FUEL VALVE KIT
11 1 O-RING KIT
12 4 SCREW (M5 x 16) 70 8
13 1 COVER
14 1 SPRING
15 1 O-RING
16 1 DIAPHRAGM
17 1 FITTING
18 2 CLAMP
19 1 CLAMP
20 1 AIR VALVE ASSEMBLY
21 4 CLAMP
22 1 O-RING KIT
23 1 O-RING KIT
24 1 AIR PLUG
25 1 ELBOW
26 6 FUEL INJECTOR
27 1 SEAL
28 1 HOSE ASSEMBLY-Air Balance
29 1 HOSE ASSEMBLY-Fuel Balance
30 1 HOSE ASSEMBLY-Fuel Supply
31 1 HOSE ASSEMBLY-Air By Pass
32 1 HOSE ASSEMBLY-Fuel By Pass
33 2 CLAMP (18.3)
34 4 STUD (M10 x 91)
35 4 NUT (M10)
36 1 SCREW (M5 x 35)
37 1 CLAMP-Hose Support
38 4 CLIP-Conduit Support
39 1 CLAMP-Worm Gear
