DIRECT FUEL INJECTION
Page 3B-32
90-888438 JUNE 2002
4. Connect fuel hose from top of low pressure fuel pump to 90° elbow on back side of
vapor separator. Secure hose with 18.3 mm full circle clamp (54-880141) using crimp-
ing tool 91-803146T.
57966
a
a
a-Secure Fuel Hose with 18.3 mm Full Circle Clamp (54-880141)
