DIRECT FUEL INJECTION
Page 3B-53
90-888438 JUNE 2002
COMPRESSOR REMOVAL
1. Disconnect battery cables from battery terminals.
2. Remove flywheel cover.
3. Use 3/8 inch (9.5 mm) drive on belt tensioner arm to relieve belt tension. Remove belt.
a
b
57806
a-Belt Tensioner
b-3/8 in. (9.5 mm) drive
