35
ECP and EPP m
odes are only supported with EPP- and ECP-aware peripherals.
EPP Mode Select (EPP 1.7)
The onboard parallel port is EPP spec. compliant, after y
ou choose the on-
board parallel port with EPP
function. Set the EPP version to 1.7 spec or 1.9
spec.
ECP Mode Use DMA (3)
When the onboard parallel port is set to ECP
mode, the parallel port
can use
DMA
3 or DMA
1.
38
40
