Component Location
TRANSOM VIEW (EXTERNAL)
1 - Drain valve
2 - Engine plate
3 - WIN number
FRONT VIEW
1 - Lifting handle
2 - Towing d‑ring
3 - Rubbing strake
1
2
3
66426
66427
BOAT COMPONENTS
eng 21
