Air Deck® Floor Installation (Models with Air Floor)
Instructions for installing floorboards in Quicksilver models with an inflatable
floor.
If you fully inflate the air deck, it will push itself underneath the tube and it will
stay there tight in its place. In the back of the boat there are two transom tracks
fixed against the transom. To fix the floor at the transom, you have to slide the
flaps that are attached at the back of the floor through the track.
1. Put the flaps A at the after side of the floor in the transom track B.
2. Install the thrust board C at the forward most point of the port and
starboard tubes. The thrust board must be placed under the air floor and
on top of the keel D on the reinforced spot that you find on the inside in
front of the tubes.
3. Place the deflated air floor D in the bottom of the inflated boat (DO NOT
inflate the keel). Make sure the hole is exactly on top of the keel valve.
a. Inflate the inflatable floorboard to approximately 50% air pressure.
OPERATION
eng 29
