Page #78 background imageLoading...
Page #78 background image
Shown on:
Name Description Value
Units (*=user
selected)
Explanation
Eng.
tab
Ves.
tab
X XDRPb Sensor supply voltage B 5.00 Volts
The 5 V reference voltage that is supplied to the shift demand
sensor and throttle demand sensor (mechanical engines only).
The normal value is 5 V, plus or minus a few hundredths of a
volt.
X XDRPc Sensor supply voltage C 5.00 Volts
The 5 V reference voltage that is supplied to the MAP sensor,
optional oil level sensor, and SmartCraft sensors. The normal
value is 5 V, plus or minus a few hundredths of a volt.
CDS G3—Live Data
Page 3C-8 © 2018 Mercury Marine 90-8M0146617 eng JULY 2018
