Setting up the multimedia controller
21
Communications connections
The following table gives details of the communications
connections:
Use this connection To connect to this
COMMS Other Meridian 500 Series
equipment, and the master digital
speaker.
RS232 The serial port of a PC, to
configure the 562V. See
Configuring the multimedia
controller using a computer,
page 35.
TRIGGERS 1,2 Trigger outputs, which can be used
to switch external equipment. They
may also be used to provide
function-select for SCART; for
more information please refer to
your dealer.
Video connections
The composite video connections should be made with high-
quality 75Ω screened cable. We do not recommend the use of
audio cables, which do not have adequate shielding or the
correct impedance, or cables intended for UHF applications, as
these do not provide adequate shielding in the 1-30MHz region.
The S-video connections should be made using S-video cables
with miniDIN plugs.
