23
Meritor Differential Carrier 18X
2 Maintenance
Fig. 2.26
Fig. 2.27
Fig. 2.28
NOTE: At this stage do not fit seal.
10. Remove any burrs found on flange with the aid of a small
ball nosed grinding wheel.
(Fig. 2.26)
11. Refit flange and pinion lock nut only to set pre-load on
bearings. (Fig. 2.27)
12. Lock flange with service tool MST4400 - CT13 (Fig. 2.28)
