Meritor Differential Carrier 18X
2 Maintenance
Differential bearing assembly
1. Apply assembly oil to the differential case (Fig 2.35)
Install the bearing cones on both sides of the differential case
(Figs.2.36 - 2.38). Use a press and suitable tools (MST4903-
L.H. / MST4707-CT47 - R.H.). Press the cones squarely and
firmly on differential cases with a press force of 6 - 8 tons.
NOTE: The larger bearing is fitted to the drive gear side of the
ring gear.
Fig. 2.35 Fig. 2.36
Fig. 2.37 Fig. 2.38
