Type B applied parts: seat, armrest, foot plate, joystick module.
Classification: Internal powered equipment by 24 VDC, Class II in charging mode.
Mains connection of battery charger: 100-120 VAC, 50/60 Hz.
Braking information: 1) Running brake: Your electrical wheelchair is equipped
with electromagnetic and regenerative brakes. Uses electricity to rapidly slow the
wheelchair when the joystick returns to the center/stop position and acts as a parking
brake.
2) Parking brake: when the joystick is in center position acts as an electromagnetic brake
In freewheel mode an assistant has is in to operate the parking brake by engaging the
drive system again. No battery power is necessary for this function.
To engage or disengage the drive motors:
1. Locate the lever on the top of the power base.
2. Push both levers forward away from the seat post to engage the drive motors
(drive mode).
3. Pull both lever rearward toward the seat post to disengage the drive motors
(freewheel mode).
