Merits P322 - Operating Your Powerbase Wheelchair; Seat, Armrest, Footrest, and Headrest Adjustments

5. Make sure the shroud front end
touches the front frame and then slightly
move the shroud from rear to front. This
will make the front hooks attach to the
bracket at the frame.
6. Push the rear end of the shroud. This
will make the rear shroud hooks attach
to the bracket at the battery tray.
20
(Fig D8)
Fig D8
Fig D9
(Fig D9)
a
