07
Technical Specs:
Load Capacity
158kg (350 lbs)@45° or 136kg (300 lbs)@55°
Range of Stair Angle
25°~55°
Note: According to ASME A18.1, no lift should be
installed to operate on a
reater incline than 45
deg. as measured on the mean.
Travel Speed
6 m/min. (20 ft/min)
Maximum Travel
9.75m (32 ft)
Drive System
Rack and Pinion
Operator Control
Constant-pressure type (rocker switch and remote
controller)
Operating Voltages
24VDC rechargeable batteries
Motor
1/2 HP, 24VDC
Brake (Optional)
Electromagnetic brake
Charging
On the top or bottom stop of the rail.
Input: 115/230VAC, 50/60Hz.
Output: 24V
2A
Operating Ambient Temperature (Humidity)
5°C ~ 40°C ( 41°F ~ 104°F )
(up to 95% non-condensing)
(up to 2,000m in altitude)
Storage/ Transport Temperature (Humidity)
(up to 95% non-condensing)
-10°C ~ 60°C ( 14°F ~ 140°F )
