5. DESCRIPTION
Backrest
Armrest
Rail
Rocker Switch
Seat Belt
Folding Seat
Safety Edge
Folding Footrest Safety Edge
Carriage
On/Off Switch
Key Switch
Status Display
Swivel Seat Handle
The Stairlift consists of four parts: the carriage, the footrest, the seat, and the
rail. The stairlift is powered by the rechargeable batteries inside the carriage.
There are safety sensors on upper and lower covers and bottom of footrest.
These sensors will stop the unit if any obstruction is detected on the rail or
stairway. The footrest, the armrests and the seat can be folded up when not
in use to allow more space on the stairway. Pull the swivel handle up to
unlock the seat when you reach the top of the stairs. This will allow you to
get into or out of the seat at a convenient position. The rail has two charging
points at the top and bottom. The batteries will be recharged automatically
when the unit stops at these positions.
Emergency Stop
Button (optional)
