Merlin MT50EVO - Accessories; Accessory Wiring Diagram

17
ACCESSORIES
8
7
9
1
6
E840M
E128M
E1702M
C77
E940M
E943M
E945M
10
4
5
E950M
E138M
2
E952M
3
(1) Model E128M Wireless wall button
(2) Model E138M Wireless wall button
(3) Model E952M 2 Channel remote control
(4) Model E950M 4 Channel remote control
(5) Model E940M 1 Channel visor remote control
(6) Model E943M 3 Channel visor remote control
(7) Model E945M 3 Channel mini remote control
(8) Model E840M Keyless entry system
(9) Model C77 The Protector System
TM
(10) Model E1702M Quick release lock
28
ACCESSORY WIRING DIAGRAM
29
NOTE: Only genuine Merlin accessories are approved for use with this opener. Generic compatible accessories are NOT approved for use with this opener.
