CARTON INVENTORY
(
1) Opener
(2) Hand held transmitter (2)
(3) Curved door arm
(4) Hanging bracket (2)
(5) Rail brackets (3)
(6) Header bracket
(
7) Door bracket
(8) Hardware bag
(9) Rail assembly
(10) Manual
(11) Warning Labels
(12) Rail centre bracket
Y
our garage door opener, rail and hardware are packed in a single carton.
2
RAIL SIZES AVAILABLE
3
NOTE: The Ceiling Fixing Point is measured back from the lintel (see item 1 to 7 of “completed installation”). Also
allow 300 mm back from the fixing point for installation of the powerhead (item 7 to 9 of “completed installation”).
3
DOOR HEIGHT:
Sectional Doors
RAIL LENGTH: CEILING FIXING
POINT:
OVERALL LENGTH:
Up to 2.5 m 3300 mm segmented 3150 mm 3450 mm
