Merlin Power Systems version: 2.0.2
SmartGauge Installation and User Guide
Page 2
Merlin’s SmartGauge battery monitoring system is designed to provide highly accurate battery
voltage and SoC (State of Charge) information in a reliable, easy to use package.
Simple to install, the SmartGauge monitor provides much more accurate battery state information
than conventional “amp hour counters”, all without the need for installing additional shunts and
heavy cabling.
As the Merlin SmartGauge significantly differs from most battery monitoring equipment, please
take time to carefully read this manual in order to understand the correct method of installation
and user functions. Failure to do so may result in permanent damage to the SmartGauge and/or
other electrical systems.
Once the unit has been correctly installed, the benefits of acquiring the Merlin SmartGauge will
become fully evident.
If any questions arise after reading this manual, further technical support can be obtained from your
local dealer or Merlin Power Systems directly:
Europe: Tel: +44 (0) 1202 697979 North America: Tel: +1 (631) 594 5102
CONTENTS OF THIS GUIDE
1.0 Introduction Page 2
1.1 Main SmartGauge Features Page 3
1.2 Why SmartGauge? Page 3
1.3 Certificates of Conformity / Caution Notes Page 4
2.0 Quick Start Guide Page 5
3.0 SmartGauge Installation Basics Page 8
3.1 Important Installation Notes Page 8
3.2 Initial Start-Up Page 9
3.3 Battery Charge Status Page 9
3.4 Power Up after Power Loss Page 10
4.0 Basic Monitor Use Page 11
5.0 Set-Up Menu - Introduction Page 12
5.1 Set Up Menu – Battery Types Page 13
5.2 Set Up Menu – Charge Status Page 14
5.3 Set-Up Menu – Alarm Functions Page 14
5.4 Set-Up Menu – Primary Alarms Page 15
5.5 Set-Up Menu – Secondary Alarms Page 18
5.6 Set-Up Menu – Defeating Error Codes Page 19
5.7 Set-Up Menu – Displays Page 19
5.8 Set-Up Menu – Display Brightness Page 20
5.9 Set-Up Menu – Menu Lock Page 20
6.0 Error Codes Page 20
7.0 Reset to Factory Defaults Page 22
8.0 Alarm Outputs Page 22
9.0 SmartGauge in Conjunction with SmartBank Page 22
9.1 Warranty Page 23
10.0 SmartGauge Flowcharts Page 24/25
