15
How to install the electrical connection
2 Feed in the connection cable:
from behind:
– push the rubber sleeves supplied A over the stripped connecting
cable.
from below:
– cut the rubber insert supplied B according to the cable thickness.
– Insert the rubber insert into the wall connection box
– Push through the connection cable
3 Mount the wall connection box using the screws supplied.
|
Note: Fuse the ARGUS using a 16 A automatic circuit-breaker
Figure ):
1 Strip the connecting cable insulation by a length of 14 mm.
2 Insert the external conductor into terminal "L".
3 Insert the neutral conductor into terminal "N".
4 Insert the connected external conductor into terminal "
↓".
"Through-wiring" to other loads is permitted.
|
Note When switching inductive loads such as transformers, relays,
contactors or fluorescent lamps, spikes occur which could lead to
the load being switched on again ("maintained light effect").
Connect a capacitor (542895) parallel to the inductive load in order
to reduce these spikes.
