17
How to mount the ARGUS upper section
Figure =:
1 Place the ARGUS upper section onto the connection box and fasten
it using the two screws provided (A). The electrical connection from
the terminal box to the pins is established automatically when the
screws are tightened.
2 Position the cover plate at the markings on the side, and guide it
upwards (B).
Figure ?:
1 Connect the supply voltage
The load is switched on for approx. 10 s or for the set period.
The functional display lights up for approx. 10 s.
Using operating elements:
All settings, such as sensitivity and switching time, can be adjusted using
the ARGUS operating elements: these are located underneath the cover
plate, which protects them. To open:
1 Push up the cover plate until you feel it hit the stop (approx. 5 mm)
and pull it off.
ARGUS displays and operating elements:
Figure >:
A Functional display: lights up whenever movement is detected
B Brightness sensor: must not be covered
C Setting the brightness threshold
D Setting the switching duration
How to mount the ARGUS upper section
How to put the ARGUS into operation
