Installing the Access Points
© 2010 Meru Networks, Inc. Installing AP150 75
AP150 Required Tools
Installing the Access Points
Selecting a Location
The AP150 requires a location that meets the following criteria:
Relatively unobstructed access to the stations the AP serves
Power over Ethernet (PoE) connection to the network switch servicing the
controller.
APs can obtain their power from 802.3af standard Power over Ethernet (PoE)-compat-
ible network switch or PoE power injector installed between the switch and the
AP150.
AP150 and AP300 work with all switches that support STANDARD 802.3af.
Installation Type Tools Required
Horizontal mounting None
Vertical mounting over a wall stud
Drill
1/8”drill bit
Screwdriver
1/8”Allen wrench
Vertical mounting on sheetrock
Drill
3/16” drill bit
Screwdriver
1/8”Allen wrench
Horizontal mounting below a
hanging ceiling
Screwdriver
Wrench or pliers
1/8”Allen wrench
Mounting above a hanging ceiling
Wrench or pliers
Screwdriver
1/8”Allen wrench
