Mesa/Boogie MARK VII

PAGE 54
WIRING SCHEMES...Amplifier to Speaker Cabinets
8 Ohm Cabinet
16 Ohm Cabinet
SAFE MISMATCH
8 Ohm Cabinet
SAFE MISMATCH
4 Ohm Cabinet
1 2
3 4
SPEAKERS
8 OHM 4 OHM
8 OHM 4 OHM
USE WITH TWO 16Ω CABS
USE WITH TWO 8Ω CABS
INTERNAL LOAD ACTIVE WHEN SPEAKER DISCONNECTED
SPEAKERS
8 OHM 4 OHM
8 OHM 4 OHM
USE WITH TWO 16Ω CABS
USE WITH TWO 8Ω CABS
INTERNAL LOAD ACTIVE WHEN SPEAKER DISCONNECTED
SPEAKERS
8 OHM 4 OHM
8 OHM 4 OHM
USE WITH TWO 16Ω CABS
USE WITH TWO 8Ω CABS
INTERNAL LOAD ACTIVE WHEN SPEAKER DISCONNECTED
SPEAKERS
8 OHM 4 OHM
8 OHM 4 OHM
USE WITH TWO 16Ω CABS
USE WITH TWO 8Ω CABS
INTERNAL LOAD ACTIVE WHEN SPEAKER DISCONNECTED
