QUICK MEASURING GUIDE
NOTE
The cus can be connected to either of the MESI TUBELESS CUFF UNIT.
The colour, size and positioning will be automatically detected by the MESI
TUBELESS CUFF UNIT.
Step 2 Place the cus to the appropriate arm/leg
ARM:
• Position the cu 1-2 cm above the elbow joint. Align the label Artery with the Artery on inner
side of an arm.
• Place the cu so that there is two fingers’ width of room between the limb and the cu.
• Check that you have chosen the correct size using the INDEX marking and the OK area of
the cu.
ANKLE:
• Position the cu 2-3 cm above the ankle. Make sure that the label Ankle points towards
inner side of an ankle.
• Place the cu so that there is two fingers’ width of room between the limb and the cu.
Check that you have chosen the correct size using the INDEX marking and the OK area on
the cu.
