ENGLISH en
11
The screwdriver bit is retained if a bit clamping bush
(as an accessory: order no. 6.31281)
is fitted.
Futuro Plus keyless chuck
See page 4, illustration A.
Unscrew the safety screw - if avail
able. Caution:
left-handed thread!
Hold the drill spindle securely using an open-end
wrench. Clam
p an Allen key in the chuck and strike
lightly with a rubber hammer to loosen, then
unscrew.
Geared chuck
See page 4, illustration B.
Unscrew the safety screw - if avail
able. Caution:
left-handed thread!
Hold the drill spindle securely using an open-end
wr
ench. Insert the key in the chuck and strike lightly
with a rubber hammer to loosen, then unscrew.
8. Maintenance
Keyless chuck cleaning:
After prolonged use hold the
chuck vertically, with
the opening facing down, and fully open and close it
several times. The dust collected falls from the
opening. Regular use of cleaning spray on the jaws
and jaw openings is recommended.
f
9. Accessories
Use only genuine Metabo accessories.
Use only accessories which fulfil the requirements
a
nd specifications listed in these operating instruc-
tions.
Fit accessories securely. Secure the machine if it is
o
perated in a bracket. Loss of control can cause
personal injury.
For a complete range of accessories, see
ww
w.metabo.com or the main catalogue.
10. Repairs
Repairs to electrical tools must be carried out by
qualified electricians ONLY!
Contact your local Metabo repres
entative if you
have Metabo power tools requiring repairs. For
addresses see www.metabo.com.
You can download a list of spare parts from
ww
w.metabo.com.
11. Environmental Protection
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: Never dispose of
power tools in your ho
usehold waste! In
accordance with European Guideline 2002/
96/EC on used electronic and electric
equipment and its implementation in national legal
systems, used power tools must be collected
separately and handed in for environmentally
compatible recycling.
12. Technical Specifications
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
P
1
=Nominal power input
P
2
=Power output
n
0
=No load speed
n
1
=Speed at rated load
ø max =Max. solid drill diameter
s max =Max. impact rate
G =Drill spindle thread
H =Drill spindle with hexagon socket
m =Weight without mains cable
D =Collar diameter
Measured values determined in
conformity with
EN 60745.
Machine in protection class II
~ Alternating current
The technical specifications quoted are subject
to
tolerances (in compliance with the relevant valid
standards).
Emission values
Using these values, you can estimate the emis-
sions from this power tool and compare these with
the values emitted by other power tools. The actual
values may be higher or lower, depending on the
particular application and the condition of the tool or
power tool. In estimating the values, you should also
include work breaks and periods of low use. Based
on the estimated emission values, specify protective
measures for the user - for example, any organisa-
tional steps that must be put in place.
Vibration total value (vector sum of three directions)
de
termined in accordance with EN 60745:
a
h, ID
=Vibration emission value (impact drilling
into concrete)
a
h, D
=Vibration emission value
(drilling into metal)
K
h,ID
,K
h,D
=Uncertainty (vibration)
Typical A-effective perceived sound levels:
L
pA
=Sound pressure level
L
WA
=Acoustic power level
K
pA
, K
WA
= Uncertainty
During operation the noise level can exceed
80 dB(A).
Wear ear protectors!
