ENGLISH en
9
Original instructions
1. Conformity Declaration
We declare under our sole responsibility: These
impact drills / drills, identified by type and serial
number *1), comply with all relevant requirements of
the directives *2) and standards *3). Technical file
at *4) - see page 3.
2. Specified Use
SBE 561, SBE 550, SBE 521, SB 561:
The impact drill is suitable for non-impact drilling in
metal, wood, pla
stic and similar materials and
impact drilling in concrete, stone and similar
materials.
BE 561, B 561:
The drill is suitable for non-impact drilling in metal,
w
ood, plastic and similar materials.
SBE 561, SBE 550, SBE 521, BE 561:
The impact drill is suitable for
thread cutting and
screwdriving.
The user bears sole responsibility for any damage
c
aused by improper use.
Generally accepted acciden
t prevention
regulations and the enclosed safety information
must be observed.
3. General Safety Instructions
For your own protection and for the
protection of your electrical tool,
pay
attention to all parts of the text that are
marked with this symbol!
WARNING – Reading the operating instruc-
tions will reduce the risk of injury.
WARNING Read all safety warnings and
instructions. Failure to follow all safety warn-
ings and instructions may result in electric shock,
fire and/or serious injury.
Keep all safety instructions and information for
fu
ture reference.
Pass on your electrical tool only t
ogether with these
documents.
4. Special Safety Instructions
Always wear hearing protection when using
hammer drills. Exposure to noise can cause loss
of hearing.
Use the additional handle supplied with the
tool. Lo
ss of control can lead to injuries.
Hold the power tool by insulated gripping
s
urfaces when performing an operation where
the cutting accessory may contact hidden
wiring or its own cord. Cutting accessory
contacting a "live" wire may make exposed
metal parts of the power tool
"live" and shock the
operator.
Pull the plug out of the pl
ug socket before any
adjustments or servicing are performed.
Beware of gas/water pipes and electric cables!
Avoid inadvertent starts by
always unlocking the
switch when the plug is removed from the mains
socket or in case of a power cut.
Keep hands away from the rotating tool!
Remove chips and similar material only with the
mac
hine at standstill.
Caution must be exercised when driving screws into
har
d materials (driving screws with metric or
imperial threads into steel)! The screw head may
break or a high reverse torque may build up.
The machine produces powerful forces when
seiz
ing or catching the workpiece. Always hold the
machine firmly, adopt a steady stance and focus on
your work.
Secure small workpieces. For
example, clamp in a
vice.
Dust from material such as paint containing lead,
so
me wood species, minerals and metal may be
harmful. Contact with or inhalation of the dust may
cause allergic reactions and/or respiratory diseases
to the operator or bystanders.
Certain kinds of dust are classi
fied as carcinogenic
such as oak and beech dust especially in
conjunction with additives for wood conditioning
(chromate, wood preservative). Material containing
asbestos must only be treated by specialists.
- Where the use of a dust extraction device is
po
ssible it shall be used.
- The work place must be well ventilated.
- The use of a dust mask of filter class P2 is
recommended.
Follow national requirements for
the materials you
want to work with.
5. Overview
See page 2.
1 Chuck key (for geared chuck) *
2Geared chuck *
3 Futuro Plus keyless chuck *
4Depth stop *
5 Additional handle *
6 Direction switch *
7 Sliding switch for normal drilling/impact drilling *
8 Lock button (continuous operation)
9Trigger
10 Speed preselection wheel *
* depending on the features / model
6. Commissioning
Before plugging in, check to see that the
rated mains voltage and mains frequency,
as stated on the rating label, match with your
power supply.
