OPERATING MANUAL
E. Electrical Parts
Item No. Name Model Specication Function
QF Protector 3VE1015 2NU00
14-20A
Motor overload
M Main Motor Y132S-4
4/5.5/7.5Kw
Pump start
FU1-FU5 Fuses RT18-32
8A
Short circuit protecting
SB1 Button KH-2022ER
250VA; 6A
Emergency stop
SB2 Stop Button KH-2022 Pump start
SB3 Switch KH-3022-2 Auto-inch
SB4 Stop Switch KH-3022 Auto-stop
SB5 Foot Panel WLCA2-2
5A
Upper beam down
SB6 Foot Panel WLCA2-2 Upper beam up
SB7 Switch KH2022
250VAC; 6A
Auto start
SB8 Switch KH2022 Table ap up
SB9 Switch KH2022 Table ap down
KM Contactor 3TB-43
25A
Circuit contactor
KA1-KA4 Relay 3TB-82
10A
Pressure control
KT Relay AH3-3
5
Folding plate down relay
SQ1 Switch LX19-001
5
Upper beam up control
SQ2 Switch LX19-001
5
Table ap up control relay
SQ3 Switch LX19-001
5
Table ap down control relay
HL Indicator AD17KA-22 Indicator light
KB Switch KBK5-160
160VA
Control pressure valve
FA Switch FAGOR
25A
Circuit switching
YV1-YV5 Pressure Valve LIXIN Hydraulic oil control
