25
OPERATING MANUAL
Panbrake
NC-89 Controller Operation
WARNING: Please read the “Panbrake Hydraulic Clamp Manual” before clamping.
Angle SV: Desired programmed angle.
Operation: Move Arrow to Angle SV, clear value , enter desired angle value. Example: 5 = 5º, and press .
Angle PV: Actual position of apron.
Operation: Angle PV is a digital readout for the apron angle as the apron moves. This is visual only and can not be modied.
Dwell Time: Desired time apron will dwell after it has reached Angle SV. Auto function only
Operation: Move Arrow to Dwell Time, clear value
, enter desired value. Example: 2 = 2 seconds, and press .
Open Height: Desired height the clamp opens after apron returns to zero. Auto function only
Operation: Move Arrow to Open Height, clear value
, enter desired value. Example: 3 = 3 seconds, and press .
Clamp Operation: See “Man-06 (Panbrake-Hyd-Clamp-Setup-Operation).pdf” manual before clamping material.
Manual Bend: Switch mode to manual. Example: Enter 90º in Angle SV. Clamp material and use the Up Manual Button to bend
material. Button can be released at any time and apron will stop. NC-89 with stop apron at 90º. Release button and bend more/less
or return back to 0º and unclamp with foot pedal.
WARNING: The apron will automatically bend up once the start button is pressed.
Auto Bend: Switch mode to Auto. Example: Enter 90º in Angle SV, Enter 2 sec in Dwell Time, Enter 3 sec in Open Height. Clamp
material and press green start button on NC-89. Apron will automatically bend up to 90º, dwell for 2 seconds, return to 0º and then
clamp will open for 3 seconds. Job complete.
Emergency Stop: Press this button to stop operation at any time in case of emergency in manual or auto mode.
Clear
Stop
Start
Manual
Auto
Arrow
Manual
Bend
Up / Down
Emergency
Stop
