MetalMaster PB-440A/T User Manual

4
OPERATING MANUAL
is METALMASTER Panbrake machine has been designed to operate safely and correctly
e machine must NOT be operated before reading this User‘s Manual. Operate the machine only
if it is in a perfect condition and in accordance with the work regulations of your factory and oper-
ating instructions of this manual.
1.1 Specications
1. GENERAL MACHINE INFORMATION
Machine Type PB-440A/T PB-825A/T PB-830A/T PB-1030T
Bending Length (mm) 1300 2500 2500 3050
Material Capacity Mild Steel (mm) 4 2.5 4 3.2
Stainless Steel (mm) 2 1.2 2 1.6
Bending Angle Indicator (deg) 0-120 0-120 0-120 0-120
Box Depth Of Fingers (mm) 230 215 205 205
Opening Height (mm) 140 140 140 140
Weight (kgs) 1250 1740 2900 3730
System Pressure (Mpa) 5 5 5 5
Pan Movement (mm/sec) 5 5 5 5
Clamp Movement (mm.sec) 10 10 10 10
Oil Tank Volume (ltr) 80 80 100 100
Back Gauge Range (mm) 1000 1000 1000 1000
Main Motor 3Ph 415v 50Hz
3.75 3.75 5.5 5.5
1.2. Standard Equipment
q Electric motor: 415V 3phase
q Top nger segments
q Back-gauge assembly
q Side guarding
q Oil tank level indicator
q Foot switch and control panel
e above specications were current at the time this manual was published, but because of our policy of
continuous improvement, Metalmaster reserves the right to change specications at any time and without
prior notice, without incurring obligations.

MetalMaster PB-440A/T Specifications

General

Brand	MetalMaster
Model	PB-440A/T
Category	Industrial Equipment
Language	English
