52 UNT Controller—Unitary Controller (UNT)
R1
Lighting
Relay
120 VAC 24 VAC
fcwire
VA1
BINARY INANALOG INPUTS BINARY OUTPUTS
Triac to
Common
Jumper
ANALOG
Fan
Relay
Power
Transformer
120/24 VAC
TE1
RM-T
RM-SP
ON
COM
OFF
AC
COM
IN+
1
2
3
IN
24 VAC
Figure 27: Fan Coil Wiring Example
Table 19: Fan Coil Bill of Materials
Component Part Number
C1 Digital Controller
AS-UNT111-1
TE1 Zone Temperature Sensor
TE-6400 Metastat
VA1 Valve Actuator
VA-8052 Valve Actuator Assembly
R1 Lighting Relay
GE-RR7
Bill of Materials
