Kit Assembly
(Figure A)
(Figure C)
(Figure B)
1. Peel away the paper backing from the
foam strip and attach it to the front
of the speaker adapter plate. (This
will enhance the performance of the
aftermarket speaker). (Figure A)
2. Mount the aftermarket speaker to the
speaker adapter plate with the screws
supplied with speaker. (Figure B)
3. Re-connect the battery terminal and test
the speaker for proper operation. Mount
the assembly to the door frame with
(4) #14 x 1/2” Phillips screws supplied.
(Figure C)
(PASSENGER
SIDE APPLICATION
SHOWN IN
ILLUSTRATION)
