95-1005
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Open ashtray and unclip and remove
side panels.
(Figure A)
2
2003-2006 KIA SORRENTO
(EXCLUDING SPORT MODELS)
Remove (8) Phillips screws from the
radio trim panel the remove the
panel.
(Figure B)
3
Remove (4) Phillips screws securing
radio.
(Figure C)
4
DASH DISASSEMBLY
A
B
C
