Metra Electronics 95-1005 - 2002-2005 Kia Sedona Dash Disassembly

95-1005
2
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Remove the ashtray and (1) Phillips
screw exposed in the ashtray cavity.
(Figure A)
2
2002-2005 KIA SEDONA
Unclip and remove the small trim
panel from around radio, climate
controls and shifter.
(Figure A)
3
Remove (4) Phillips screws from the
radio trim panel then unclip and
remove the panel.
(Figure B)
4
Remove (4) Phillips screws securing
radio.
(Figure C)
5
DASH DISASSEMBLY
A
B
C
