95-1005
3
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Remove the ashtray and (1) Phillips
screw exposed in the ashtray cavity.
(1 Phillips screw exists in 2002 model
only).
(Figure A)
2
2002-2005 KIA RIO
Unclip and remove entire panel sur-
rounding radio and climate controls.
(On 2002 models remove knob from
fresh air/recirculate control).
(Figure B)
3
Remove (4) Phillips screws securing
radio.
(Figure C)
4
DASH DISASSEMBLY
A
B
C
